SECTION 6—OPERATING INSTRUCTIONS
Part No 1160877 19 Perfecto
2
™Series
3. Insertaflatheadscrewdriverintheplategrooveonthetop
edgeofthefilteraccessdoorandgentlyprythefilter
accessdooroff(FIGURE6.2).
4. Pullupandremovethehumidifierbottleadapter
(FIGURE6.2).
5. Replacethefilteraccessdoorandinstalltheairscooponto
thefilteraccessdoorbyinsertingthesixtabsontheairscoop
intothesixslotsonthesidesofthefilteraccess door.
FIGURE 6.2 Humidifer Bottle Adapter
6. Attachthehumidifierbottleadaptertothehumidifier
bottlebyturningthewingnutonthehumidifierbottle
counterclockwiseuntilitissecurelyfastened.SeeDetail
“A” inFIGURE6.3.
7. Placethehumidifierbottle/adapterassemblyinthe
humidifiercompartmentontheconcentrator.SeeDetail
“B”inFIGURE6.3.
8. Attachoxygentubingfromthehumidifierbottle/adapter
assemblytooxygenoutletconnectorontheconcentrator.
SeeDetail“B”inFIGURE6.3.
9. Attachthecannula/patient supplytubingtothe
humidifierbottleoutlet.SeeDetail“B”inFIGURE6.3.
Insert Flat
Head
Screwdriver
Here
Filter Access
Door
Humidifier Bottle
Adapter
Cabinet Filter
Air Scoop
Tabs
Slots

Invacare Perfecto2 IRC5PO2AW Specifications

General

Flow Rate	0.5 to 5 LPM
Warranty	3 years limited
Operating Environment	10°C to 35°C; up to 95% relative humidity
Power Requirements	120 VAC, 60 Hz
Sound Level	≤45 dB(A)
Dimensions	23 in (H) x 13 in (W) x 12 in (D) (58.4 cm (H) x 33 cm (W) x 30.5 cm (D))
