Invacare Perfecto2 IRC5PO2AW User Manual

SECTION 7—MAINTENANCE
Perfecto
2
™Series 24 Part No 1160877
SECTION 7—MAINTENANCE
 WARNING
TheInvacareconcentratorsarespecificallydesignedto
minimizeroutinepreventivemaintenance.Onlyqualified
personnelshouldperformpreventivemaintenanceonthe
concentrator.
Unplugtheconcentrator whencleaning.Toavoidelectrical
shock,DONOTremovecabinet.
NOTE:Ataminimum,preventivemaintenanceMUSTbe
performedaccordingtothemaintenancerecordguidelines.Inplaces
withhighdustorsootlevels,maintenancemayneedtobeperformed
moreoften.RefertoPreventiveMaintenanceRecordonpage 26.
Routine Maintenance
Thefollowingroutinemaintenanceshouldbeperformedmore
frequently.Seerecommendedintervalsineachsectionand
PreventiveMaintenanceRecordonpage 26.
Cleaning the Cabinet Filter
CAUTION
DONOToperatetheconcentratorwithoutthefilterinstalled.
NOTE:Forthisprocedure,refertoFIGURE7.1onpage 25.
NOTE:Thereisonecabinetfilterlocatedonthebackofthecabinet.
1. Inspectthefiltermonthly.Removethefilterandcleanas
needed.
NOTE:Environmentalconditionsthatmayrequiremorefrequent
inspectionandcleaningofthefilterinclude,butarenotlimitedto:
highdust,airpollutants,etc.

Invacare Perfecto2 IRC5PO2AW Specifications

General

Flow Rate	0.5 to 5 LPM
Warranty	3 years limited
Operating Environment	10°C to 35°C; up to 95% relative humidity
Power Requirements	120 VAC, 60 Hz
Sound Level	≤45 dB(A)
Dimensions	23 in (H) x 13 in (W) x 12 in (D) (58.4 cm (H) x 33 cm (W) x 30.5 cm (D))
