SECTION 6—OPERATING INSTRUCTIONS
Part No 1160877 21 Perfecto
2
™Series
Flowrate
NOTE:Forthisprocedure,refertoFIGURE6.5.
NOTE:TakecarenottosettheflowaboveREDring.Anoxygen
flowgreaterthan5L/minwilldecreasetheoxygenconcentration.
1. Turntheflowrateknobtothesettingprescribedbyyour
physicianortherapist.
 WARNING
DONOTchangetheL/minsettingontheflowmeterunlessa
changehasbeenprescribedbyyourphysicianortherapist.
NOTE:Toproperlyreadtheflowmeter,locatetheprescribedflowrate
lineontheflowmeter.Next,turntheflowknobuntiltheballrisesto
theline.Now,centertheballontheL/minlineprescribed.
2. Iftheflowrateontheflowmetereverfallsbelow0.5L/minfor
morethanaboutone minute,theLOWFLOWalarmwillbe
triggered.Thisisarapidbeepingoftheaudiblealarm.Check
yourtubingoracce ssoriesforblockedorkinkedtubingora
defective humidifierbottle.Afterratedflowisrestoredtomore
than0.5L/min,theLOWFLOWaudiblealarmwillgooff.
NOTE:Theuseofsomeaccessoriessuchasthepediatricflowstand
andtheHomeFillcompressorwilldeactivatetheLowFlowAlarm.
FIGURE 6.5 Flowrate
Flow Knob
Ball
Flowmeter
Front Panel
0.5 L/min

Invacare Perfecto2 IRC5PO2AW Specifications

General

Flow Rate	0.5 to 5 LPM
Warranty	3 years limited
Operating Environment	10°C to 35°C; up to 95% relative humidity
Power Requirements	120 VAC, 60 Hz
Sound Level	≤45 dB(A)
Dimensions	23 in (H) x 13 in (W) x 12 in (D) (58.4 cm (H) x 33 cm (W) x 30.5 cm (D))
