SECTION 6—OPERATING INSTRUCTIONS
Perfecto
2
™Series 18 Part No 1160877
Youroxygenconcentratorwillperformbestwhenoperated
undertheconditionsoutlinedintheTypicalProduct
Parametersonpage 13.Usageinenvironmentsotherthan
thosedescribedmayresultintheneedforincreased
equipmentmaintenance.Theairintakeoftheunitshouldbe
locatedinawellventilatedareatoavoidairbornepollutants
and/orfumes.DONOTuseinacloset.
Set Up
1. Pluginpowercordtoanelectricaloutlet.
2. ConnectHumidifier(ifsoprescribed).
 WARNING
DONOToverfillhumidifier.
DONOTreversetheoxygeninputandoutputconnections.
Waterfromthehumidifierbottlewilltravelthroughthe
cannulabacktothepatient.
NOTE:Forthisprocedure,refertoFIGURE6.1,FIGURE6.2on
page 19,FIGURE6.3onpage 20.
1. Removecapfrombottle.
2. Fillhumidifierwithdistilledwatertothelevelindicated
bythemanufacturer.Replacethehumidifiercapand
securelytighten.
FIGURE 6.1 Filling the Humidifier
Humidifier
Bottle w/o Cap
Humidifier
Bottle with Cap

Invacare Perfecto2 IRC5PO2AW Specifications

General

Flow Rate	0.5 to 5 LPM
Warranty	3 years limited
Operating Environment	10°C to 35°C; up to 95% relative humidity
Power Requirements	120 VAC, 60 Hz
Sound Level	≤45 dB(A)
Dimensions	23 in (H) x 13 in (W) x 12 in (D) (58.4 cm (H) x 33 cm (W) x 30.5 cm (D))
