SECTION 6—OPERATING INSTRUCTIONS
Perfecto
2
™Series 22 Part No 1160877
SensO
2
Oxygen Purity Indicator - Models
IRC5PO2AW & IRC5PO2VAW
Thisfeaturemonitorsthepurityofoxygengeneratedbythe
oxygenconcentrator.Ifpurityfallsbelowfactorypreset
standards,indicatorlightsonthecontrolpanelwill
illuminate.
Initial Startup of the Concentrator
NOTE:Concentratormaybeusedduringtheinitialstartwarm‐up
time(approximately30min.)whilewaitingfortheO
2
purityto
reachmaximum.
Whentheunitisturnedon,theGREENlightwillcomeon
(SYSTEMOK/O2greaterthan85%).Afterfiveminutes,the
oxygensensorwillbeoperatingnormallyandwillcontrolthe
indicatorlightsdependingonoxygenconcentrationvalues.
Explanation of Oxygen Purity Indicator Lights -
Model IRC5PO2AW & IRC5PO2VAW
NOTE:Forthisprocedure,refertoFIGURE6.6onpage 23.
GREENlight(O
2
)‐NormalOperation.
YELLOWlight()‐Immediatelycallsupplier.Youmay
continuetousetheconcentratorunlessinstructedotherwise
byyoursupplier.Becertainthatbackupoxygenisnearby.
REDlight()‐Totalunitshutdown.Immediatelyswitchto
backupoxygensupplyandcallsupplier.
GREENlight‐withYELLOWlightflashing‐Immediatelycall
supplier.Oxygensensormalfunctioning;youmaycontinueto
usetheconcentrator.

Invacare Perfecto2 IRC5PO2AW Specifications

General

Flow Rate	0.5 to 5 LPM
Warranty	3 years limited
Operating Environment	10°C to 35°C; up to 95% relative humidity
Power Requirements	120 VAC, 60 Hz
Sound Level	≤45 dB(A)
Dimensions	23 in (H) x 13 in (W) x 12 in (D) (58.4 cm (H) x 33 cm (W) x 30.5 cm (D))
