Invacare Robin Installation And Technical Manual

A
B
C
41
7.5.2 Traverse rail system
Parallel rail
Traverse rail
S-profile M-profile L-profile
S-profile
A = 83 mm
C =156 mm
M-profile
B = 156 mm
C = 203 mm
A = 129 mm
B = 203 mm
C = 250 mm
L-profile C = 272mm C = 319 mm
A = 198 mm
B = 272 mm
C =388 mm
