Function
code
Name
Description
Default
value
P08.16
Amplitude of jump frequency
0.0–50.0% (relative to amplitude of
wobbling frequency)
0.0%
P08.17
Wobbling frequency rise
time
0.1–3600.0s
5.0s
P08.18
Wobbling frequency fall time
0.1–3600.0s
5.0s
5.5.17 Local encoder input
The GD350 IP55 series VFD supports pulse count function by inputting the count pulse from
HDI high-speed pulse port. When the actual count value is no less than the set value, digital
output terminal will output count-value-reached pulse signal, and the corresponding count
value will be zeroed out.
Function
code
Name
Description
Default
value
P05.00
HDI input type
0x00–0x11
Ones: HDIA input type
0: HDIA is high-speed pulse input
1: HDIA is digital input
Tens: HDIB input type
0: HDIB is high-speed pulse input
1: HDIB is digital input
0x00
P05.38
HDIA high-speed pulse input
function
0: Set input via frequency
1: Reserved
2: Input via encoder, used in combination
with HDIB
0
P05.44
HDIB high-speed pulse input
function selection
0: Set input via frequency
1: Reserved
2: Input via encoder, used in combination
with HDIA
0
P20.15
Speed measurement mode
0: PG card
1: local; realized by HDIA and HDIB;
supports incremental 24V encoder only
0
P18.00
Actual frequency of encoder
-999.9–3276.7Hz
0.0Hz
5.5.18 Commissioning procedures for closed-loop control, position control and spindle
positioning
1. Commissioning procedures for closed-loop vector control of asynchronous motor
Step 1: Restore to default value via keypad
Step 2: Set P00.03, P00.04 and P02 group motor nameplate parameters
Step 3: Motor parameter autotuning
Carry out rotary parameter autotuning or static parameter autotuning via keypad, if the motor
