INVT GD350-015G/018P-45-AS

Goodrive350 IP55 High-ingress Protection Series VFD Function parameter list
-212-
Function
code
Name
Description
Default
value
Modify
0: No filter
1: Filter
Bit3: Reserved
Bit4: Enable/disable pulse reference filter
0: No filter
1: Filter
Bit5: Pulse reference filter mode (valid when Bit4
is set to 1)
0: Self-adaptive filter
1: Use P20.19 filter parameters
Bit6–15: Reserved
P20.18
Encoder pulse
filter width
0–63
0 means 0.25μs
2
○
P20.19
Pulse reference
filter width
0–63
0 means 0.25μs
2
○
P20.20
Pulse number of
pulse reference
0–65535
1024
◎
P20.21
Enable angle
compensation of
synchronous
motor
0–1
0
○
P20.22
Switch-over
frequency
threshold of
speed
measurement
mode
0–630.00Hz
1.00Hz
○
P20.23
Synchronous
motor angle
compensation
coefficient
-200.0–200.0%
100.0%
○
P20.24
Number of pole
pairs in inital
magnetic pole
angle autotuning
1–128
2
◎
P21––Position control
Function
code
Name
Description
Default
value
Modify
P21.00
Positioning
mode
0x0000–0x7121
Ones: Control mode selection (only for FVC)
0: Speed control
1: Position control
Tens: Position command source
0: Pulse train, using PG card terminal (A2, B2)
0x0000
○
