Goodrive350 IP55 High-ingress Protection Series VFD Basic Operation Instructions
-68-
Rated speed of
asynchronous motor 2
Rated voltage of
asynchronous motor 2
Rated current of
asynchronous motor 2
Stator resistance of
asynchronous motor 2
Rotor resistance of
asynchronous motor 2
Leakage inductance of
asynchronous motor 2
Mutual inductance of
asynchronous motor 2
No-load current of
asynchronous motor 2
Rated power of synchronous
motor 2
Rated frequency of
synchronous motor 2
0.01Hz–P00.03 (max. output frequency)
Number of pole pairs of
synchronous motor 2
Rated voltage of
synchronous motor 2
Rated current of
synchronous motor 2
Stator resistance of
synchronous motor 2
Direct-axis inductance of
synchronous motor 2
Quadrature-axis inductance
of synchronous motor 2
Counter-emf constant of
synchronous motor 2
5.5.7 Start/stop control
The start/stop control of the VFD is divided into three states: start after running command at
power-up; start after restart-at-power-cut function is effective; start after automatic fault reset.
Descriptions for these three start/stop control states are presented below.
There are three start modes for the VFD, which are start at starting frequency, start after DC
brake, and start after speed-tracking. Users can select the proper start mode based on field
conditions.
For large-inertia load, especially in cases where reversal may occur, users can choose to start
after DC brake or start after speed-racking.
