INVT GD350-015G/018P-45-AS

Goodrive350 IP55 High-ingress Protection Series VFD Expansion cards
-292-
Appendix A Expansion cards
A.1 Model definition
EC-PG 5 01-05 B
① ② ③ ④ ⑤
⑥
Field
Field description
Naming example
①
Product category
EC: Expansion card
②
Card category
IC: IoT card
IO: IO card
PC: Programmable card
PG: PG card
PS: Power supply card
TX: Communication card
③
Technical version
Indicates the generation of technical version by using
an odd number. For example, 1, 3, 5, and 7 indicate the
1st, 2nd, 3rd and 4th generations of technical version.
④
Distinguishing code
01: Incremental PG card + frequency-divided output
02: Sine/Cosine PG card + pulse direction setting +
frequency-divided output
03: UVW PG interface + pulse direction setting +
frequency-divided output
04: Resolver PG interface + pulse direction setting +
frequency-divided output
05: Incremental PG card + pulse direction setting +
frequency-divided output
06: Absolute PG interface + pulse direction setting +
frequency-divided output
07: Simple incremental PG card
⑤
Working power
00: Passive
05: 5V
12: 12–15 V
24: 24 V
⑥
Expansion card version
Empty: Version A
B: Version B
C: Version C
EC-PC 5 02-00
① ② ③ ④ ⑤
Field
Field description
Naming example
①
Product category
EC: Expansion card
②
Card category
IC: IoT card
IO: IO card
