INVT GD350-015G/018P-45-AS

Goodrive350 IP55 High-ingress Protection Series VFD Function parameter list
-209-
Function
code
Name
Description
Default
value
Modify
P19.10
EC PT100
detected
temperature
-50.0–150.0°C
0.0°C
●
P19.11
EC PT100
detected digital
0–4096
0
●
P19.12
EC PT1000
detected
temperature
-50.0–150.0°C
0.0°C
●
P19.13
EC PT1000
detected digital
0–4096
0
●
P19.14
Alarm display
0–4
0: No alarm
1: PT100 detected OH alarm (A-Ot1)
2: PT1000 detected OH alarm (A-Ot2)
3: PT100 disconnection alarm (A-Pt1)
4: PT1000 disconnection alarm (A-Pt2)
0
●
P19.15
VFD control
word
0–65535
0
●
P19.16
VFD status word
0–65535
0
●
P19.17
Ethernet
monitoring
variable 1
0–65535
0
●
P19.18
Ethernet
monitoring
variable 2
0–65535
0
●
P19.19
Ethernet
monitoring
variable 3
0–65535
0
●
P19.20
Ethernet
monitoring
variable 4
0–65535
0
●
P19.21
AI/AO detected
temperature
-20.0–200.0°C
0.0°C
●
P20––Encoder of motor 1
Function
code
Name
Description
Default
value
Modify
P20.00
Encoder type
display
0: Incremental encoder
1: Resolver-type encoder
2: Sin/Cos encoder
3: Endat absolute encoder
0
●
P20.01
Encoder pulse
number
Number of pulses generated when the encoder
revolves for one circle.
Setting range: 0–60000
1024
◎
P20.02
Encoder
0x000–0x111
0x000
◎
