INVT GD350-015G/018P-45-AS

Goodrive350 IP55 High-ingress Protection Series VFD Function parameter list
-210-
Function
code
Name
Description
Default
value
Modify
direction
Ones: AB direction
0: Forward
1: Reverse
Tens: Z pulse direction (reserved)
0: Forward
1: Reverse
Hundreds: CD/UVW pole signal direction
0: Forward
1: Reverse
P20.03
Detection time of
encoder offline
fault
0.0–10.0s
2.0s
○
P20.04
Detection time of
encoder reversal
fault
0.0–100.0s
0.8s
○
P20.05
Filter times of
encoder
detection
Setting range: 0x00–0x99
Ones: Low-speed filter time, corresponds to
2^(0–9)×125μs.
Tens: High-speed filter times, corresponds to
2^(0–9)×125μs.
0x33
○
P20.06
Speed ratio
between
encoder
mounting shaft
and motor
Users need to set this parameter when the
encoder is not installed on the motor shaft and
the drive ratio is not 1.
Setting range: 0.001–65.535
1.000
○
P20.07
Control
parameters of
synchronous
motor
0x0000–0xFFFF
Bit0: Enable Z pulse calibration
Bit1: Enable encoder angle calibration
Bit2: Enable SVC speed measurement
Bit3: Select resolver speed measurement mode
Bit4: Z pulse capture mode
Bit5: Do not detect encoder initial angle in v/f
control
Bit6: Enable CD signal calibration
Bit7: Disable sin/cos sub-division speed
measurement
Bit8: Do not detect encoder fault during
autotuning
Bit9: Enable Z pulse detection optimization
Bit10: Enable initial Z pulse calibration
optimization
Bit11: Reserved
Bit12: Clear Z pulse arrival signal after stop
Bit13: Reserved
Bit14: Detect Z pulse after one rotation
Bit15: Reserved
0x0003
○
