INVT GD350-015G/018P-45-AS

Goodrive350 IP55 High-ingress Protection Series VFD Function parameter list
-225-
Function
code
Name
Description
Default
value
Modify
P24.18
Encoder pulse
filter width
0–63
The filtering time is P24.18×0.25 μs. The value 0
or 1 indicates 0.25 μs.
2
○
P24.19
Pulse reference
filter width
0–63
The filtering time is P24.19×0.25 μs. The value 0
or 1 indicates 0.25 μs.
2
○
P24.20
Pulse number of
pulse reference
0–16000
1024
◎
P24.21
Enable angle
compensation of
synchronous
motor
0–1
0
○
P24.22
Switch-over
frequency
threshold of
speed
measurement
mode
0–630.00Hz
1.00Hz
○
P24.23
Synchronous
motor angle
compensation
coefficient
-200.0–200.0%
100.0%
○
P24.24
Number of pole
pairs in inital
magnetic pole
angle autotuning
1–128
2
◎
P25––Expansion I/O card input functions
Function
code
Name
Description
Default
value
Modify
P25.00
HDI3 input type
selection
0: HDI3 is high-speed pulse input
1: HDI3 is digital input
0
◎
P25.01
S5 terminal
function
The same with P05 group
0
◎
P25.02
S6 terminal
function
0
◎
P25.03
S7 terminal
function
0
◎
P25.04
S8 terminal
function
0
◎
P25.05
S9 terminal
function
0
◎
P25.06
S10 terminal
function
0
◎
