5.3.2 Displaying running-state parameters
After receiving valid running command, the VFD will enter running state, and the keypad
displays running state parameter with RUN indicator on the keypad turning on. In running state,
multiple kinds of state parameters can be displayed. Press or to shift the displayed
parameter up or down.
Figure 5-5 Running-state parameter display 1
GD350
16:02:35
Output Freq
P17.01 Hz
50.00
Set Freq
P17.00 Hz
50.00
540.0
DC Bus Volt
P17.11 V
GD350
16:02:35
Set Freq
P17.00 Hz
50.00
DC Bus Volt
P17.11 V
540.0
378
Output Volt
P17.03 V
Fwd
Local Run
Fwd
Local
Run
AboutParameter
Menu
AboutParameter
Menu
Press or to switch between different display styles, including list display style and
progress bar display style.
Figure 5-6 Running-state parameter display 2
GD350
16:02:35
Fwd
Local Run
DC Bus Volt
Back
Home
0.0 2000.0
GD350
16:02:35
Fwd
Local Run
DC Bus Volt
P17.11 V
540.00
Outp Volt
P17.03
0x0000
0x0000
AboutParameter
Menu
Outp Cur
P17.04
540.00
V
In running state, multiple kinds of state parameters can be displayed. The running display
parameter list is user defined, and each state variable function code can be added to the
running display parameter list as needed. A function code which has been added to the
running display parameter list can also be deleted or shifted.
5.3.3 Displaying fault information
The VFD enters fault alarm display state once fault signal is detected, and the keypad displays
fault code and fault information with TRIP indicator on the keypad turning on. Fault reset
operation can be carried out via STOP/RSTkey, control terminal or communication command.
The fault code will be kept displaying until fault is removed.
