Goodrive350 IP55 High-ingress Protection Series VFD Function parameter list
-158-
Function
code
Name
Description
Default
value
Modify
(0–1000)
15: Value 2 set through Modbus/Modbus TCP
(0–1000)
16: Value 1 set through
PROFIBUS/CANopen/DeviceNet (0–1000)
17: Value 2 set through
PROFIBUS/CANopen/DeviceNet (0–1000)
18: Value 1 set through Ethernet 1 (0–1000)
19: Value 2 set through Ethernet 2 (0–1000)
20: HDIB input (0.00–50.00kHz)
21: Value 1 set through
EtherCAT/PROFINET/Ethernet IP (0–1000)
22: Torque current (bipolar, 0–Triple the motor
rated current)
23: Exciting current (bipolar, 0–Triple the motor
rated current)
24: Set frequency (bipolar, 0–Max. output
frequency)
25: Ramp reference frequency (bipolar, 0–Max.
output frequency)
26: Rotational speed (bipolar, 0–Speed
corresponding to max. output frequency)
27: Value 2 set through
EtherCAT/PROFINET/Ethernet IP (0–1000)
28: AO1 from the Programmable card (0–1000)
29: AO2 from the Programmable card (0–1000)
30: Rotational speed (0–Twice the motor rated
synchronous speed)
31: Output torque (Actual value, 0–Twice the
motor rated torque)
32: AI/AO temperature detection output
33–63: Reserved
P06.17
Lower limit of
AO1 output
Above function codes define the relation
between output value and analog output. When
the output value exceeds the set max./min.
output range, the upper/low limit of output will be
adopted during calculation.
When analog output is current output, 1mA
corresponds to 0.5V voltage. In different
applications, 100% of output value corresponds
to different analog outputs.
0.0%
○
P06.18
Corresponding
AO1 output of
lower limit
0.00V
○
P06.19
Upper limit of
AO1 output
100.0%
○
P06.20
Corresponding
AO1 output of
upper limit
10.00V
○
P06.21
AO1 output filter
time
0.000s
○
