Goodrive350 IP55 High-ingress Protection Series VFD Function parameter list
-196-
Function
code
Name
Description
Default
value
Modify
(unsigned)
23: High-order bit of position feedback
(signed)
24: Low-order bit of position feedback
(unsigned)
25: Status word
26: HDIB frequency value (x100, kHz)
27: High-order bit of PG card pulse feedback
28: Low-order bit of PG card pulse feedback
29: High-order bit of PG card pulse reference
30: Low-order bit of PG card pulse reference
31: Function parameter mapping (PZD2–
PZD12 correspond to P14.60–P14.70)
P15.24
Reserved
P15.25
DP communication
timeout time
0.0 (invalid)–60.0s
5.0
○
P15.26
CANopen
communication
timeout time
0.0 (invalid)–60.0s
5.0
○
P15.27
CANopen
communication
baud rate
0–7
0: 1000kbps
1: 800kbps
2: 500kbps
3: 250kbps
4: 125kbps
5: 100kbps
6: 50kbps
7: 20kbps
3
◎
P15.28
Master/slave CAN
communication
address
0–127
1
◎
P15.29
Master/slave CAN
communication
baud rate selection
0: 50Kbps
1: 100 Kbps
2: 125Kbps
3: 250Kbps
4: 500Kbps
5: 1M bps
2
◎
P15.30
Master/slave CAN
communication
timeout period
0.0 (invalid)–300.0s
0.0s
○
P15.31–
P15.42
Reserved
P15.43
Communication
control word
expression format
0–1
0: Decimal format
1: Binary format
0
◎
