INVT GD350-015G/018P-45-AS

Goodrive350 IP55 High-ingress Protection Series VFD Expansion cards
-296-
Name
Model
Specification
VFD locally or remotely through WIFI communication
 The maximum communication distance in open
environments is 30 m.
 EC-TX501-1 is equipped with a built-in antenna and
applicable to molded case machines.
 EC-TX501-2 is configured with an external sucker
antenna and applicable to sheetmetal machines.
PROFIBUS-DP
communication card
EC-TX503
Supporting the PROFIBUS-DP protocol
Ethernet
communication card
EC-TX504
 Supporting Ethernet communication with INVT's internal
protocol
 Can be used in combination with INVT's upper
computer monitoring software INVT Workshop
CANopen
communication card
EC-TX505
 Based on the CAN2.0A physical layer
 Supporting the CANopen protocol
PROFINET
communication card
EC-TX509
Supporting the PROFINET protocol
Ethernet/IP
communication card
EC-TX510
 Supporting the Ethernet IP protocol and ODVA protocol
 With two Ethernet IP ports, supporting 10/100M half/full
duplex operating
 Supporting star, line, and ring network topologies (but
not supporting ring network monitoring)
CAN master/slave
control
communication card
EC-TX511
 Based on the CAN2.0B physical layer
 Adopting INVT's master-slave control proprietary
protocol
Modbus TCP
communication card
EC-TX515
 With two Modbus TCP IO ports, supporting 100M full
duplex operating, and supporting line and star network
topologies, with the nodes up to 32
 Able to function as a Modbus TCP slave
Sin/Cos PG card
EC-PG502
 Applicable to Sin/Cos encoders with or without CD
signals
 Supporting A, B, Z frequency-divided output
 Supporting input of pulse train reference
UVW incremental PG
card
EC-PG503-05
 Applicable to 5V differential encoders
 Supporting A, B, Z orthogonal input
 Supporting U, V, W 3PH pulse input
 Supporting A, B, Z frequency-divided output
 Supporting input of pulse train reference
Resolver PG card
EC-PG504-00
 Applicable to resolver encoders
 Supporting simulated A, B, Z frequency-divided output
of resolvers
 Supporting input of pulse train reference
Multi-function
incremental PG card
EC-PG505-12
 Applicable to OC encoders of 5 V or 12 V
 Applicable to push-pull encoders of 5 V or 12 V
 Applicable to differential encoders of 5 V
 Supporting the orthogonal input of A, B, and Z
 Supporting the frequency-divided output of A, B, and Z
 Supporting pulse train setting
