INVT GD350-015G/018P-45-AS

Goodrive350 IP55 High-ingress Protection Series VFD Basic Operation Instructions
-79-
Function
code
Name
Description
Default
value
P05.28
Input filter time of AI1
0.000s–10.000s
0.100s
P05.29
Lower limit value of AI2
-10.00V–P05.31
-10.00V
P05.30
Corresponding setting of
lower limit of AI2
-300.0%–300.0%
-100.0%
P05.31
Intermediate value 1 of AI2
P05.29–P05.33
0.00V
P05.32
Corresponding setting of
intermediate value 1 of AI2
-300.0%–300.0%
0.0%
P05.33
Intermediate value 2 of AI2
P05.31–P05.35
0.00V
P05.34
Corresponding setting of
intermediate value 2 of AI2
-300.0%–300.0%
0.0%
P05.35
Upper limit value of AI2
P05.33–10.00V
10.00V
P05.36
Corresponding setting of
upper limit of AI2
-300.0%–300.0%
100.0%
P05.37
Input filter time of AI2
0.000s–10.000s
0.100s
P05.38
HDIA high-speed pulse input
function
0: Set input via frequency
1: Reserved
2: Input via encoder, used in
combination with HDIB
0
P05.39
Lower limit frequency of
HDIA
0.000 kHz – P05.41
0.000kHz
P05.40
Corresponding setting of
lower limit frequency of HDIA
-300.0%–300.0%
0.0%
P05.41
Upper limit frequency of
HDIA
P05.39 –50.000kHz
50.000kHz
P05.42
Corresponding setting of
upper limit frequency of
HDIA
-300.0%–300.0%
100.0%
P05.43
HDIA frequency input filter
time
0.000s–10.000s
0.030s
P05.44
HDIB high-speed pulse input
function selection
0: Set input via frequency
1: Reserved
2: Input via encoder, used in
combination with HDIA
0
P05.45
Lower limit frequency of
HDIB
0.000 kHz – P05.47
0.000kHz
P05.46
Corresponding setting of
lower limit frequency of HDIB
-300.0%–300.0%
0.0%
P05.47
Upper limit frequency of
HDIB
P05.45 –50.000kHz
50.000kHz
P05.48
Corresponding setting of
upper limit frequency of
HDIB
-300.0%–300.0%
100.0%
