7
Output power
0–Twice the rated power of motor
8
Set torque value
0–Twice the motor rated current. A
negative value corresponds to 0.0% by
default.
9
Output torque
0 – +/-(Twice the motor rated torque)
10
AI1 input value
0–10V/0–20mA
11
AI2 input value
0V–10V. A negative value corresponds
to 0.0% by default.
12
AI3 input value
0–10V/0–20mA
13
Input value of high-speed pulse HDIA
0.00–50.00kHz
14
Value 1 set through Modbus/Modbus TCP
communication
0–1000
15
Value 2 set through Modbus/Modbus TCP
communication
0–1000
16
Value 1 set through
PROFIBUS/CANopen/DeviceNet
communication
0–1000
17
Value 2 set through
PROFIBUS/CANopen/DeviceNet
communication
0–1000
18
Value 1 set through Ethernet
communication
0–1000
19
Value 2 set through Ethernet
communication
0–1000
20
Input value of high-speed pulse HDIB
0.00–50.00kHz
21
Value 1 set through EtherCAT/PROFINET/
EtherNET IP communication
0–1000. A negative value corresponds
to 0.0% by default.
22
Torque current (bipolar)
0–Triple the motor rated current. A
negative value corresponds to 0.0% by
default.
23
Exciting current
0–Triple the motor rated current. A
negative value corresponds to 0.0% by
default.
24
Set frequency (bipolar)
0–Max. output frequency. A negative
value corresponds to 0.0% by default.
25
Ramp reference frequency (bipolar)
0–Max. output frequency. A negative
value corresponds to 0.0% by default.
26
Running speed (bipolar)
0–Synchronous speed corresponding
to max. output frequency. A negative
value corresponds to 0.0% by default.
27
Set value 2 of
EtherCAT/PROFITNET/Ethernet IP
communication
0–1000
