INVT Goodrive200A Series User Manual

GD200A series VFD Function parameters
-37-
Function
code
Name
Description
Default
value
Modify
or P00.07 does not equal to 6, but the setting step
can only be the 1–15 steps. The setting step is
0–15 if P00.06 or P00.07 equals 6.
7: PID control setting
The running mode of the VFD is process PID
control when P00.06=7 or P00.07=7. It is
necessary to set P09. The running frequency of
the VFD is the value after PID effect. See P09 for
the detailed information of the preset source,
preset value, and feedback source of PID.
8: MODBUS communication setting
The frequency is set by MODBUS communication.
See P14 for detailed information.
9–11: Reserved
P00.08
B frequency
command
reference
0: Maximum output frequency, 100% of B
frequency setting corresponds to the maximum
output frequency
1: A frequency command, 100% of B frequency
setting corresponds to the maximum output
frequency. Select this setting if it needs to adjust
on the base of A frequency command.
0
○
P00.09
Combination of
the setting
source
0: A, the current frequency setting is A frequency
command
1: B, the current frequency setting is B frequency
command
2: A+B, the current frequency setting is A
frequency command + B frequency command
3: A-B, the current frequency setting is A
frequency command - B frequency command
4: Max (A, B): the bigger one between A frequency
command and B frequency is the set frequency.
5: Min (A, B): The lower one between A frequency
command and B frequency is the set frequency.
Note: The combination manner can be shifted by
P05(terminal function)
0
○
P00.10
Keypad set
frequency
When A and B frequency commands are selected
as "keypad setting", this parameter will be the
initial value of VFD reference frequency
Setting range: 0.00 Hz–P00.03 (the max.
frequency)
50.00
Hz
○
