9. Troubleshooting
Diagnostics
Error Code
Description
Resolution
1
Sensor configuration error
Contact distributor
2
Flash memory error
Contact distributor
3
i2c bus error
Contact distributor
4
i2c bus to fuel gauge error
Contact distributor
5
Calibration fail
1. Check calibration setup
2. Check calibration gas connection to the
calibration dock
3. Contact distributor
6
Sensor power
Contact distributor
7
Lamp strike fail
1. Replace electrode stack
2. Replace lamp
3. Contact distributor
8
i2c ADC error
Contact distributor
9
ADC range error
Contact distributor
11
Internal temperature of the
cub is too high
The Cub will stop charging until the temperature is
less than 45°C. Leave device to cool in the dock, or
move to a cooler ambient environment
A
PID sensor connection
issue
1. Try fitting a known working Mini PID
2. Contact distributor
