Technical Specifications
Cub Specifications
Response time:
T90 < 13 second
Detectable ranges:
ppm:
0 to 5,000 ppm (0.1 ppm sensitivity)
ppb:
0 to 5,000 ppm (0.001 ppm sensitivity)
TAC:
0 to 5,000 ppm (0.01 ppm sensitivity)
Resolution:
Depends on the model (see Detection range, above.)
Accuracy:
+/- 5% displayed reading +/- one digit
Linearity:
+/- 5% displayed reading +/- one digit
Battery:
Lithium ion, 12 hours
Data log:
Including date / time: 30,000
Alarm visual:
Flashing Red and Amber LED
Alarm audible:
95 dB @ 300 mm
Flow Rate:
Not applicable (no pump)
Temperature:
Operating:
-20 to 60 C (-4 to 140 F)
Storage:
-25 to 60 C (-13 to 140 F)
Certified to:
-20 to 55C (-4 to 131F)
Dimensions (Instrument):
61mm x 66mm x 59mm (2.4” x 2.6” x 2.3”)
Weight (Instrument):
111g (3.9 oz)
Ingress protection:
with PTFE filter fitted:
IP65
with PTFE filter removed:
IP64
