1 Rubber multi-function push button.
2 LCD display.
3 Alarm Sounder.
4 PID (Photo-ionisation Detector).
5 Clip and D-ring loop.
Cub Doc Docking Stations
The Cub is used with Cub Doc Docking Stations. These are used to recharge your Cub. Depending on
which model of Docking Station you use, they can also be used to download data from your Cub, and
to calibrate it.
Cub Docs are equipped with coloured LEDs to indicate battery, connection, and calibration status.
There are three types of Cub Docs:
Cub Doc Type
Charges device
LED status
indicators
USB connection
Calibration
Charge Dock




Data Dock




Calibration Dock




