⚫ Power input : 15A / 90-120VAC , 10A / 210-240VAC , 50-60Hz.
⚫ Maximum loading of each output: 10Amp
⚫ Maximum of Total loading : 10Amp
⚫ Fuse protection : 10Amp
⚫ Dimensions: 200 x 140 x 35 mm ( L x W x H )
⚫ Weight: g
⚫ Enclosure – Matel case in deep Gray color
⚫ Operation Temperature : -10 ~ 60 ℃ or 14 ~104(℉)
⚫ Note : Use the magnetic “ Latching Relay “ (a KEEP relay ) , operation temperature
can go up to 85°C (185 °F) with MTBF 100K times , longer electrical life
expectancy . It keeps device operating temperature at low state and maintain there
without going higher even all 4 port at ON state simultaneously , plus lower power
consumption for energy savings purpose. When power is turned OFF, all contacts
are available for other circuit functions and maintains its position, the circuit will be
in the same state when power is turned ON again.
Minimum System Requirements
⚫ Network & Web Browser & Internet Connection
⚫ Ethernet Cable & Power Cord
Package Contents
⚫ 9828 Unit
⚫ Online CD note : www.aviosys.com/cd
