Hardware Connection
Before hardware connection, please make sure that there is no more than 2 net
work card ( include dynamic network card ) . If there are morn than two network
card in your PC. You may not get the IP address of 9828
The default setting of 9828 `s IP is by DHCP assigned by Router. The connection sequence is
different as connect to Router or connect to PC directly. Please refer following procedure :
A. 9828 ------- Router ------- PC ( with Web browser )
1.) Connect the Ethernet cable (RJ45) to the 9828 to your local area network.
2.) Then connect the power cable into the power input port of the 9828.
3.) Connect the device that you would like to control to the output plug on the top of the 9828.
4.) Switching the power source to ON status , this switch is located at the rear of 9828.
5.) After power on for around 45 seconds , there is a short beep sound for 9828 which means
the system reboot successfully
B. 9828 ------------- PC ( with Web browser )
If you select to connect to PC directly , please connect the RJ45 cable to 9828 after 1 minutes as
power on of the 9828 device . power hear the beep sound of 9828 DO NOT connect the RJ45 as
power ON
If you select to connect to you PC to 9828 directly :
1.) Connect the power cable to 9828 and press the power switch to ON
2.) After 9828 power on for around 45 seconds , there is a short beep sound for 9828 which
means the system reboot successfully
3.) Then Connect the Ethernet cable (RJ45) to the 9828 to your PC.
6.) Execute the software IPEDIT.exe to get the IP as 192.168.1.169
7.) Please make sure the IP address of you PC is also 192.168.1.X / XX/XXX or you may not
log in the 9828 webage in 192.168.1.169
