IP Power 9258 - Initial Setup and Configuration

- 8 -
Interface Description
Outlook
Front :
Switch 1& 2 for
Buttons Control outlets
The two buttons are for emergency safety switch
The default function is Toggle ( Switch ON / OFF ) .
But the buttons function can be setup as 6 modes :
OFF, ON, Shut down on Lan , Wake on Lan , Toggle or
None .
Disable , . Please go to webpage “ I/O Control “ →
“ Control “ → “ Advanced ” → “ Emergency safety switch
setting ”
Main Net 1
LAN 10/100 Mbps network for Internet
Net 2
HUB for bypass the signal of Net 1 ( LAN 10/100 Mbps network )
LED 1 & 2
Display the 2 outlets as ON or OFF
Back :
Outlet 1 & 2
IEC320 ,
Maximum Current : 10Amp ( for total two ports / single port )
Power input
15A / 90-120VAC , 10A / 210-240VAC , 50-60Hz.
Power Switch
Turn ON / OFF the power of 9828 devices.
Right Side :
Reset
Please keep pressing the button for 7 seconds and then
release .You will hear 3 short beep sound which show the reset
Successfully . After reset , all the settings , like IP, password and
so on , will be back to Default .
Setting up your device
Before Starting
*Before setting up the device make sure of the following:
1.) All the package contents are all included if anything is missing please contact the dealer
where the device was purchased from.
2.) Check the power input cable is working correctly.
3.) Check all cables to make sure there are no problems with it.
