Step 2: Connect the Wire Feeder Attachment to the Unit
1
Using a Phillips Head Screwdriver, loosen the set screw on the wire feeder unit.
2
Locate the Wire Feeder Attachment. Insert the Wire Feeder Adapter into the wire feeder unit as far as
possible without it touching the drive roll.
Warning: There should be a slight space between the adapter and drive roll to ensure it does not get
scratched and worn out.
1 Getting Started
LightWELD WireFeeder Set-Up Guide
9
