Assembling the Wire Feeder Attachment
Once the components (Drive Rolls, Liner, Contact Tip, and Extension) have been selected according to the
application, the wire feeder unit and equipment can be assembled.
VIDEO: Part 2 - Assembly
Step 1:Prepare the Liner and Housing Tube
1
Insert the Liner into the HousingTubeand feed it through, until about an inch (25.4mm) of liner extends
out from the tube. (Tube may also be black or opaque)
2
Insert the Nut on to the Liner as shown. Note that the nut has not been inserted into the housing tube.
