IPG Photonics LightWELD - Wire Configuration Kits

Wire Configuration Kits
Visit the IPGWeb Shop to order parts 24/7: IPG Photonics Shop
Hard Wire Kit - CEU00003657XXXXU
Item # Part Number Part Name QTY.
1
CMMIXXX0002838PX 0.030”-0.035” (0.8-0.9mm) V-DRIVE ROLL 2
2
CMMIXXX0002839PX 0.045''-0.063'' (1.1-1.6mm) V-DRIVE ROLL 2
3
CMUS0008377XXXXU 0.4'' (10mm) EXTENSION 1
4
CMUS0010363X01XU 0.030''-0.045'' (0.8-1.1mm) STEEL LINER 1
5
CMUS0010363X02XU 0.045''-0.063'' (1.1-1.6mm) STEEL LINER 1
6
CMMIXXX0002848PX HOUSINGTUBE 1
7
CMUS0008259XXXXU 2.283'' (58mm) TUBE 1
8
CMUS0008398002XU GROOVED NOZZLE TIP 1
9
CMUS0010223XXXXU WELDHEADADAPTER 1
10
CMUS0010224XXXXU NUT 2
11
CMUS0010225XXXXU WIREFEEDERADAPTER 1
12
P40-009401 SCREW 1
13
CMUS0011444XXXXU 0.030'' (0.8mm) CONTACT TIP 1
14
CMUS0011445XXXXU 0.035'' (0.9mm) CONTACT TIP 1
15
CMUS0011446XXXXU 0.047'' (1.2mm) CONTACT TIP 1
16
CMUS0010319XXXXU 0.063'' (1.6mm) CONTACT TIP 1
2 Replacement Parts
LightWELD WireFeeder Set-Up Guide
