Step 7: Attach Adapter to Weld Head
After the wire feeder tip assembly is complete and the synch cable is attached, the wire tip assembly can be added to the
weld head from the LightWELD.
1
Connect the Grooved Nozzle tip, proper size Extension for configuration, and 2.283’’
(58mm) Tube.
2
Insert the Tube into the head and secure by tightening the chuck. Hand tighten only.
