Drive Rolls
Drive Roll
Corresponding
Wire Diameter
Hard Wire
V-Drive Rolls
CMMIXXX0002838PX 0.030”-0.035” (0.8-0.9mm)
CMMIXXX0002839PX 0.045”-0.063” (1.1-1.6mm)
Soft Wire
U-Drive Rolls
CMMIXXX0002723PX 0.030”-0.035” (0.8-0.9mm)
CMMIXXX0002722PX 0.047”-0.063” (1.2-1.6mm)
Each drive roll has 2 different sized grooves to accommodate a range of wire diameters. Notice the drive rolls
are labeled on each side. Groove dimensions are indicated on the face opposite of the groove.
When loading the drive rolls into the drive mechanism, ensure the desired groove markings are facing out.
Once installed, the visible markings indicate the groove size that is currently in use.
