IPG Photonics LightWELD - Page 17

5
Secure the wire by pushing the drive roll covers down (1) and pushing the knobs back up into place (2).
Note: The tension on the wire can be adjusted by twisting the knobs on the drive roll mechanism. For
example, if the wire is slipping then you will need to tighten. If the wire kinks, then you will need to
reinstall the wire and loosen the tension.
1 Getting Started
14
