IRIS IRMA MATRIX - General Information; Symbols and Abbreviations; Brief Document Description

4/15
Starting IRMA MATRIX on the PC via Ethernet
released
Rev. 1.2
2016-02
1 General
1.1 Symbols / abbreviations used
"Please note!"
"Information"
"Instructions"
"Download"
"See Annex"
"See document on our website"
M12CAN-CON-03
iris product designation / name of an IRMA MATRIX component
sCON
Connector for IRMA MATRIX sensors
Connector (f)
Female connector
Connector (m)
Male connector
x, y
Variable cable executions or variable cable lengths
XX or Kq
Cable available in 2 different cable qualities
"Advanced“
Name of a window or button
1.2 Brief description
These instructions describe the steps required for connecting an IRMA MATRIX sensor to
any PC. Afterwards, a suitable software program enables for example the check of the
condition on delivery, configuration of the sensor properties, updating of the firmware or
viewing of the sensor graphic data. Communication between the sensor and the PC is
effected via Ethernet.
