Page #32 background imageLoading...
Page #32 background image
Iris Technology Operator's Manual
QuietPower 1800 (QP-1800) Doc 287.F701 / 100412
Page 32 of 56 Rev 12 APR 2010
3.7.3 Technical Specifications
Table 4 provides equipment specifications for the QuietPower 1800 Inverter system.
Table 4:Technical Specifications
Parameter
Characteristic
Continuous Power
1800 W
Surge Power
2900 W
Peak Efficiency
90 %
No Load Current Draw
< 0.92 A
Output Frequency
60 Hz 0.05 %
crystal controlled
Output Waveform
True Sine Wave
< 3 % THD
Input Voltage Range
20 - 32 VDC
Output Voltage
120 VAC RMS -10 / +4 %
Input DC Connection
Two 5/16" Posts
for Ring Lugs
Output AC Connection
Dual Receptacles with GFCI
Cabling Supplied with Inverter System
Package (PN 287A107, PN 287A120)
2/0 AWG Flexible
with NATO Plug (12 ft)
Weight
Inverter 16.5 lbs (7490 g)
Cable 18.0 lbs (8170 g)
Case 20.0 lbs (9080 g)
Size of Inverter
15.4 x 11.0 x 4.5 in
(391 x 279 x 114 mm)
Size of Cable
144.0 x 4.0 x 3.5 in
(3660 x 102 x 89 mm)
Size of Case
22.1 x 17.9 x 10.4 in
(561 x 455 x 264 mm)
Operating Temperature
-20 / +60 C
(-4 / +140 F)
Storage Temperature
-30 / +70 C
(-22 / +158 F)
Warranty
24 Months
