NAV – NAVIGATION OFF
The NAV page with navigation OFF, allows pilots to view the current navigation
source and view and change the navigation course.
Key Window Action
NAV – OFF
OFF
W1 - This window displays the current navigation
source as OFF.
W2 – Blank
NAV AID W3 - Displays NAV AID, no action when pressed.
CRS NNN
W4 - This is a data entry window with the label
CRS and the data consisting of a three-digit
number that indicates the current VHF NAV
receiver course for the VHF NAV, which has a valid
entry range of 001°-360°.
The pilot is able to insert a new NAV course using
the alphanumeric keyboard followed by a press of
the ENT button. This setting controls the selected
VHF NAV course for the PFD and NAV displays.
