SYS - ALT/SPD
On the SYS top-level page, depressing the arrow key next to W1 ALT/SPD allows the
pilot to access the ALT/SPD page, as well as view and change the altimeter setting
units and minimums annunciator status.
Key Window Action
SYS – ALT/SPD
PFD
W1 - Allows the pilot to access the ALT/SPD page
that has the same control functionality as the PFD
key.
INHG or
MBAR
W2 – Toggles the altimeter setting units as INHG
or MBAR.
The altimeter setting is displayed on the UFCP and
the MFDs using the units specified in this window.
MIN ON/OFF
W3 - Labelled MIN and the options ON and OFF.
The selection in this window controls whether or
not the MINIMUMS annunciator is displayed on the
PFD.
W4 - Has no display or control functionality.
