Identification Squawk (ID)
The ID hard key allows pilots to initiate an ID squawk from the transponder and
view the information contained in the transmission.
Pressing the ID key initiates an ID squawk and displays the ID page. After 5
seconds, the ID page is removed and the UFCP returns to its previous display.
The UFCP page can be changed away from the ID page before 5 seconds have
passed by selecting any of the master mode or page navigation hard keys.
Key Window Action
ID
XPDR
W1 - Displays the equipment identifier, which is a
data display window. The identifier displays as
XPDR left-justified.
NNNN
W2 - Is a data display window that displays data
consisting of a four-digit octal number indicating
the current transponder code.
ALT ON, ALT
OFF, SBY
W3 - Displays the current transponder mode,
which is also a data display window.
The transponder mode is displayed as ALT ON left-
justified, when selected mode is report altitude,
ALT OFF left-justified, when selected mode is do
not report altitude or SBY left-justified, if
transponder is in standby mode.
IDENT
W4 - Displays IDENT left-justified and has no
control functionality.
