39. DEDICATED PC VIEWER
Menu and function can be changed without prior notice by sudden firmware upgrade or product enhancement.
Playback Recording
Menu
Thumbnail
Drawing a lane
Print
Backup
Setup
Open
Play, Stop
Repeat event
Step Reverse, Step
Previous/Next event
Front/rear image related
Front/Rear image switch
Cutting Front/Rear image in half
Front/rear image PIP
Color/Black&white mode switch
1
6 7
6
7
8
1 5
2 8
9
10
910
11
3
4 5
4
2
3
Front/rear image playback screen
Google Map
(Only when connected with external GPS)
Recording File List
Adjust playback speed
11
Volume Control
G-Sensor(Acceleration) Graph
Speed indicator
(Only when connected with external GPS)
GPS signal receiving window
(Only when connected with external GPS)
