Irritrol KD2 User Manual

11
About the KD2 Memory
The KD2 is equipped with nonvolatile memory and will
retain program information in the event that AC power
is lost or no battery is connected. The date and time are
maintained for up to 24hours in the event that AC power
is lost, but the user has the option of installing a 9volt
battery to maintain the date and time in the absence of AC
power in excess of 24hours.
Setting a Calendar Day Schedule
The Calendar Day schedule enables you to set each day of
the week as an active or inactive watering day. Each day
can be active or inactive in each program (A, B and C).
1. Turn the control dial to Water Days position .
2. Press the button as needed to select the desired
program. Program letter A, B or C will be displayed.
3. Press either the or button to make the day
active (the watering symbol is displayed) or inactive
(the nowatering symbol is displayed) for the
selected program.
4. Press to advance to the next Water Day.
5. Repeat steps 1 and 3 for each day of the week.
6. Repeat steps 1–4 for each program as needed.
7. Return the control dial to HOME position when
nished.
Setting a Day Interval Schedule
A Day Interval schedule enables watering days to be
set without regard to the actual days of the week. For
example, a 1day interval will water every day, a 2day
interval will water every other day and so on up to a
31day interval, which will water only once a month. The
active watering day is the last day of the Interval.
In order to establish a reference point for the beginning of
the Day Interval, the current day within the interval is also
entered. For example, if a 3day interval is selected and
“Today” is entered as day 2 of the interval, then watering
will occur tomorrow (the last day of the interval).
1. Turn the control dial to the Interval position.
2. Press the button as needed to select the desired
program. Program letter A, B or C will be displayed.
Note: If Odd or Even is displayed, an Odd/Even
watering day schedule is already selected for the
program and must rst be made inactive before a Day
Interval schedule can be used. Refer to “Setting An
Odd/Even Day Schedule” for this procedure.
3. Press the or button to select the desired interval
number (01–31). The letters DY (day) are displayed to
the right of the Day Interval number.
• To remove an Interval schedule from the program,
press the or button to display    (dashes).
