Irritrol KD2 User Manual

1
Specifications
Dimensions - Indoor/Outdoor Models
6.75" W x 8.25" H x 4.25" D
(17.15 cm W x 20.96 cm H x 10.80 cm D)
Power Specications:
Indoor/Outdoor Models - Domestic
• Input: 120VAC, 50/60Hz, 0.3A
• Output: 24VAC, 50/60Hz, 0.8A
(0.4A per output, 2 outputs Max)
Indoor/Outdoor Models - Australia
• Input: 240VAC, 50Hz, 0.15A
• Output: 24VAC, 50Hz, 0.8A
Maximum Load Per Station:
0.4A @ 24VAC
Maximum Load For Pump/Master Valve:
0.4A @ 24VAC
Total Maximum Output:
One Station plus one Pump/Master Valve
Not to exceed 0.8A @ 24VAC
Temperature Limit Range:
Operating – 14ºF to 140ºF (10ºC to 60ºC)
Storage – 22ºF to 149ºF (30ºC to 65ºC)
Surge Protection:
Input: 6KV
Output: 6KV
Power Outage Protection:
Data Retention with No Battery
Date/Time Retention up to 24hours with No Battery
Outdoor Rating:
NEMA 3R, IP24
Overcurrent Protection:
Builtin Overcurrent Detection Circuit
Certications:
North America UL/cUL, Australia, FCC Part 15,
Industry Canada ICES30
Operating Specications:
Zone Timing: Each Station can water up to four hours
Start Times: Up to three Start Times per program
Day Schedule:
7Day Calendar, Day Interval, Odd Days or
Even Days
Rain Delay: You can set a delay from 1 through 7 days
Water Adjustment: Adjust from OFF (0%) up to 200% in
10% increments.
Weather Sensor: Compatible with Climate Logic
®

Weather Sensing Devices and SMRT Logic
TM
Technology.

Irritrol KD2 Specifications

General

Brand	Irritrol
Model	KD2
Category	Controller
Language	English
