7
6. Apply power to the controller. The controller needs
about 60 seconds to internally charge before station
outputs can operate. This will only occur when the
controller is initially powered up or after a power
interruption.
See Setting the Date and Time on page 7 to set
the current time and date. To quickly check sprinkler
system operation, refer to the Test Mode procedure.
Programming
Note: To select an optional display language or clock
format, refer to Display Language Option on page 18.
Setting the Date and Time
1. Turn the control dial to the Date/Time position.
2. Adjust the clock to the current hour by pressing the
or button.
Note: The display will change rapidly if either button is
pressed for more than three consecutive seconds.
3. Press the button to advance to the next eld.
4. Adjust the selected eld by pressing the or
button.
5. Repeat steps 3–4 to adjust the remaining elds of the
Date/Time display.
6. Return the control dial to HOME position when
nished.
A B C
Figure 4
US Model Non-US Model
Line Black
Neutral White
Earth Grnd Green
Line Brown
Neutral Blue
Earth Grnd Green
To Next Page
