Enable/Disable Expansion Port
Your KD2 controller is compatible with many of Irritrol’s
controller enhancement products like the Climate Logic
TM
Weather Sensing System (CL100WIRELESS) and the
Climate Logic
TM
HandHeld Remote (R100KIT) by way
of the builtin expansion port. The provided expansion
port for Climate Logic
TM
devices must be switched ON to
enable operation. See item 7 on page 2 for the location of
the expansion port. The expansion port is switched ON by
default when assembled at the factory.
1. Turn control dial to Special Functions position.
2. Press the button as needed to select the expansion
port switch option designated by XP N.
3. Press the or button to select Y (yes, expansion
port on), or N (expansion port o).
4. Return the control dial to HOME position when
nished.
Enable/Disable Rain Sensor Terminals
To utilize the sensor terminals, RS must be set to Y.
Selecting N will bypass the sensor terminals and the
controller will function normally regardless of the input at
the sensor terminals.
1. Turn control dial to Special Functions position.
2. Press the button as needed to select RS N.
3. Press the or button to select Y (yes) to enable or
N (no) to disable sensor inputs.
4. Return the control dial to HOME position when
nished.
Firmware Version
To check your KD2’s rmware version, place the control
dial to
Special Functions position and press the
button as needed until the rmware version is displayed
(V001 or later).
Automatic Circuit Breaker
The KD2 controller features an electronic circuit breaker
which automatically detects an overload condition on a
station terminal during operation and turns o the station
before controller damage can occur. The KD2 advances to
the next programmed station in sequence to continue the
watering cycle.
After the program watering cycle has nished, FUSE and
the number of the skipped station(s) will be displayed in
alternating sequence with the current time of day. If all of
the station numbers and FUSE are displayed, the master
valve is malfunctioning. Pressing any button will remove
the warning display.
Important: The most common cause of an overload
condition is a short circuit in the valve wiring or a
malfunctioning valve solenoid. The cause of the overload
condition should be corrected before continuing to operate
the controller.
