32
TXG23
Normal Starting
FIGS. 29 & 30: To start engine proceed as follows:
1. Depress brake pedal firmly and apply parking brake
lock.
2. Place range shift lever in neutral position.
3. Make sure PTO clutch lever is disengage position.
WARNING: Range shift lever must be placed
in neutral position and PTO clutch lever must
be in disengaged position.
4. Do not move hydrostatic pedal, it must be in neutral
position.
5. Set position control lever (three-position hitch) in the
down position.
6. Turn main switch to the left to "glow" position for 5-10
seconds until indicator glows.
7. Set hand throttle lever at half to fully open position.
8. Turn main switch to "on" position for 1-2 seconds,
then turn to "start" position. Release switch the
moment engine starts.
9. Once engine runs smoothly, set engine speed to
approximately 1,500 rpm to allow engine and
hydraulic system to warm for several minutes. DO
NOT LOAD COLD ENGINE.
WARNING: Range shift lever must be placed
in neutral position to actuate neutral switch
and permit operation of the starter motor.
FIG. 31: Battery charge indicator lamp, 1, and engine oil
pressure lamp, 2, on indicator light strip should go out
when the engine starts. If either light remains lit, STOP
ENGINE IMMEDIEATELY and investigate source of prob-
lem.
NOTE: If Engine will not start and run after several
attempts, refer to "Maintenance" section in this
book and bleed any air that may be present in the
fuel system.
FIG. 29
FIG. 30
FIG. 31
