TXG23
Operator Observations
Constant attention should be paid to the following points
during operation:
K
Engine oil pressure lamp will come on in case of low
engine oil pressure. Stop engine immediately.
K
Battery charge lamp will come on if battery is not be-
ing charged properly. Stop engine and investigate
cause.
K
Coolant temperature gauge needle will indicate H(hot)
in case of over-heated engine. Stop engine, allow to
cool, and investigate cause.
K
Fuel level should not be allowed to(E) empty as run-
ning out of fuel may result with need to bleed air from
fuel system.
CAUTION: DO NOT attempt to service Tractor
with engine running or hot. Allow to cool.
NOTE: Refer to "Trouble-Shooting" when defect is indi-
cated, to assist locating problem.
Starting Circuit Operation
Tractor is equipped with a switch system to protect the
operator.
To permit Tractor to be started (starter motor to operate),
ALL the following is required:
K
Range Gear Shift Lever in Neutral.
K
PTO clutch lever in disengage position.
WARNING: Neutral switch system is installed
for your protection. DO NOT bypass or modi-
fy the neutral start switch system. If the neu-
tral start switch system does not operate
properly as detailed above, contact your
Dealer immediately and have the system
repaired.
Periodically check that the starting circuit is functioning
correctly. The procedure for this is check list as follows.
1. Check that there are no bystanders around the tractor
should it inadvertently start.
2. Depress the brake pedal. Attempt to start the tractor
with the range gear and PTO in neutral position. The
Tractor should start.
3. Depress the brake pedal. Attempt to start the Tractor
with the range gear engaged and the PTO in ON
position. The Tractor should NOT start.
4. Depress the brake pedal. Attempt to start the Tractor
with the range gear in neutral and the PTO engaged.
The tractor should NOT start.
If starting system is not working correctly it must be
repaired immediately by your Dealer.
