Iseki TXG23 - Lubrication and Fill Points

50
TXG23
LUBRICATION/FILL POINTS
FIG. 56: General layout of lubrication, fill and drain loca-
tions on Tractor:
Ref. Description Type
1. Crankcase Engine Oil
2. Engine Radiator Engine Coolant
3. Fuel Tank Diesel Fuel
4. Rear Housing Hydraulic Oil
5. 4WD Axle Hydraulic Oil
6. Brake Pivots Grease
7. Leveling Turnbuckle Grease
8. 2WD Axle Grease
9. Linkage of Mower Grease
FIG. 56
