26
Interior
Full Masonry V
eneer Finished Fir
eplace Fr
onts
Isokern unit width dimension
Ex
tent of Steel
L
4”
Bearing
3
½
”
minimum
clearance
Steel L
Wo
od (Flammable)
Sheathing
8”
min
Steel L
Masonr
y
Ve
neer
Masonr
y
Ve
neer
End of Isokern
firebox unit and
steel L align
3
½
”
min
4
½
”
8”
min
Figure 30
Figure 31
25
27
