RequiredClearancetoCombustibles
Important:“Combustibles”aredenedas“normalconstructionmaterials”andconsideredtobe:woodframingmaterials,particle
board,millboard,plywoodpaneling,plywoodsubooringandwoodooring.
The IBV is listed for installation with “clearance to combustibles” (shown below) as follows:
A:Zeroinch(0”)clearancetothecombustibleoor
B:Zeroinch(0”)clearanceattheIsokernreboxandsmokedomesidesandfront
C:Oneandonehalfinches(11/2”)clearanceattheIsokernreboxandsmokedomebackwall
D: One inch (1”) minimum air space to combustibles at all B-Vent double wall chimney components’ outer layer.
(Contactpipemanufacturerforspecicclearanceinformation)
CAUTION:Maintainthreeinches(3”)clearancetoinsulationandvaporbarriersfromallrebox,smokedomeandBVentue
components’ outer layer.
Notes:
1. TheIBVisdesigned,testedandapprovedforinstallationdirectlyonacombustibleoorsystempertheinstallationspecications
given in this manual.
2.AllIBVinstallationswillresultintheminimumnishedrebrickoorofthereboxbeingatleastfourandonehalfinches
(41/2”)abovethecombustibleoorsystem.Forushhearthinstallations,consultyourlocalrepresentative.
3.Thecombustibleoorinfrontofthereplacemustbecoveredwithanoncombustiblehearthextensionmaterialsettightagainst
thereplacefrontandextendingatleasttwentyinches(20”)outfromthenishedfrontofthereplaceandatleasttwelveinches
(12”)beyondthenishedsidesofthereplaceopening(Seepage28).
WARNING:Combustibleobjectsplacedinfrontofthereplacemustbekepttoaminimumoffortyeightinches(48”)clearance
tothereplaceopening.
B
A
B
B
D
D
D
C
Combustible
Floor System
(non-insulation)
Hearth Extension
(non-combustible)
