Isokern IBV-36 Installation, Operation, Maintenance And Owner's Manual

6
AssembledFirebox&SmokeDomeDimensions
EarthcoreIndustries,LLC.reservestherighttomakechangesatanytime,withoutnotice,indesign,materialsandspecications
and also to discontinue styles and product. Phone 800-642-2920 or visit: www.earthcore.co
Side View
Front View
Plan View
A
E
F
E
G
H
C
D
B
Model
A
BC DEF
G
H
I
Minimum Framing Weight
36”
43”
25¼”
71 1/4”
31 1/2”
36 1/8” 27 1/4”
21½”
20¼” 5“
43” W x 71 1/4” H x 26 3/4”D 1500 lbs.
46”
53”
25¼ 31 1/2” 47 1/8”
37 1/4”
32”
20¼”
5“
53” W x 71 1/4” H x 26 31/4” D1700 lbs.
I
36”
43”
25¼”
81 3/4”
*42”
21½”
20¼”
5“
43” W x 81 3/4” H x 26 3/4” D
1650 lbs.
46”53” 25¼ 32”
20¼”
5“
53” W x 81 3/4” H x 26 3/4” D 1850 lbs.
*42”
*To achieve height dimension “D” in table above, a 9’ minimum flue height with 10” I.D. B-Vent is required
36”43” 25¼”
92 1/4””
*52 1/2”
21½”
20¼”
5“
43” W x 92 1/4“ H x 26 3/4” D 1800 lbs.
46”53” 25¼
92 1/4” 32”
20¼”
5“
53” W x 92 1/4” H x 26 3/4” D 2000 lbs.
*52 1/2”
81 3/4”
*To achieve height dimension “D” in table above, a 12’ minimum flue height with 10” I.D. B-Vent is required
*To achieve height dimension “D” in table above, a 100“ (8.3’) minimum flue height with 10” I.D. B-Vent is required
36 1/8”
47 1/8”
47 1/8”
36 1/8”
27 1/4”
27 1/4”
37 1/4”
37 1/4”
71 1/4”
