ITech IT-M3140 Series - M3135 E

Technical Specification
Parameter IT-M3134E
Standard Interface
Standard: USB, LAN
Optional: RS232&analog, GPIB
Isolation ( output to ground)
600VDC
Isolation (input to ground)
2200VDC
Working Temperature
0～40℃
Parallel Number
Not support
Series Number
Not support
IP IP20
Safety Standard
IEC 61010
Cooling
Air
Bare metal size ( mm)
213W*450D*88H
Whole machine size ( mm)
255W*530D*109H
Weight( net) （8±1）kg
5.1.12 IT-M3135E
Parameter IT-M3135E
Rated value
Voltage
0～600V
Current 0～10A
Power 0～1850W
Line Regulation ±(％of Out-
put+Offset)
Voltage
0.001%+20mV
Current ≤4MA
Load Regulation ±(％of
Output+Offset)
Voltage
0.004%+30mV
Current ≤7MA
Setup Resolution
Voltage
10mV
Current 1mA
Power 0.1W
Read Back Resolution
Voltage
10mV
Current 1mA
Setup Accuracy
Voltage
≤0.03% + 0.02%F.S.
Current ≤0.1% + 0.1%F.S.
Power ≤0.5%F.S.
Read Back Accuracy Voltage
≤0.03% + 0.02%F.S.
