Functions and Features
The procedures to set the output priority mode are as follows.
1. Press [Shift]+[V-set](Config） to enter into the configuration menu
interface.
2. Use knob or left and right keys to select Mode, press [Enter] to confirm.
3. Select CC Priority or CV Priority, press [Enter] to enter into the setting
interface.
• Select CV Priority, the menu displays V-Rise Time and V-Fall Time.
• Select CC Priority, the menu displays I-Rise Time and I-Fall Time.
4. Select the desired menu item, press [Enter] to confirm.
5. Use knob to adjust the values and press [Enter] to confirm.
4.1.2 Set the Output-On/Output-Off Delay Time
You can set the output-on/output-off delay time within the range from 0 seconds
to 10 seconds. During the output delay time, the VFD displays
on the top
right corner. Once the output-on delay timer expires, the VFD displays ”CC” or
“CV”. Once the output-off delay timer expires, the VFD displays ”OFF”.
• On Delay is from the time that a command to turn on the output is received
until the output actually turns on.
• Off Delay is from the time that a command to turn off the output is received
until the output actually turns off.
The procedures to set the output delay time are as follows.
1. Press [Shift]+[V-set](Config) to enter into the configuration menu interface.
2. Use knob or left and right keys to select On Delay or Off Delay and press
[Enter] to confirm.
3. Use knob to adjust the output-on/output-off delay time and press [Enter] to
confirm.
4.1.3 Set the Output Timer Function
You can set the output timer within the range from 1.0 seconds to 86400 sec-
onds. Once the timer expires, the output is turned off.
During the timing output, if the front panel has no operation for more than 5 sec-
onds, the display will show the current output time of the timer: 00:00:05 (hour:
minute:second). Press any button (except [Shift] key, [Local] key) to exit the
timing display page.
The procedures to set the output timer are as follows.
1. Press [Shift]+[V-set](Config) to enter into the configuration menu interface.
2. Use knob or left and right keys to select Timer and press [Enter] to confirm.
Copyright © Itech Electronic Co., Ltd.
39
